Fjernkontroll veggmontert for ATDM-1012/0604a

Produktnummer: ATCP-W02S

inkl. mva.

Up to four control panels can be connected to one SmartMixer (ATDM-0604a requires the use of additional ATLK-EXT165 or ATLK-EXT25 extender) Two configurable, backlit buttons (green/orange/off) and one configurable rotary button with outer surrounding LED bars (green/off) Two dedicated AT-Link ports for connecting to SmartMixer and daisy-chaining additional control panels or other AT-Link enabled products

Spesifikasjoner
Beskrivelse

Generelle spesifikasjoner
Bruttovekt	N/A kg
Produsentens varenummer	ATCP-W02S

Power Supply	DC+8～+48V (Audio-Technica LINK)
Power Consumption	1.2W
Operating Temperature	0 to 40°C
Operating Humidity Range	25 to 85 % (with no condensation)
Dimensions	86mm × 60.7mm × 86mm (W×D×H

ATCP Series products are simple, programmable control panels that provide the user with convenient and easy remote control.

Power and data transfer between the ATCP control panel and Audio-Technica SmartMixer is via Audio-Technica's dedicated AT-Link terminals, using standard Cat5e (or higher) network cables.

The control functions are configured using the SMM software application (SmartMixer Manager, PC) or via the SmartMixer’s web remote (web browser, PC or Mac).
