Expert Power Control 8021-1
Produktnummer: GUD-80211
inkl. mva.
4-fold switched and metered PDU - Expert Power Control 8021-1 for more operational security and energy efficiency in 19-inch installations
| Generelle spesifikasjoner | |
|---|---|
| Bruttovekt | N/A kg |
| Produsentens varenummer | 80211 |
4-fold switched and metered PDU
Technical Details
- Integrated type 3 overvoltage protection (L-N, L/N-PE), status retrievable via network
- High-inrush relay: max. 4 sec: 30 A /max. 20 ms: 80 A
- Measurement of key electrical parameters: current (A), voltage (V), phase angle, power factor, frequency (Hz), active power (W), apparent power (VA) and reactive power (VAr)
- Measurement of residual current type A (mA)
- Encrypted communication through SSL (TLS 1.1, 1.2, 1.3) and SSH
- 19-inches, 1 HU
- LxWxH: 43.9 x 17.8 x 4.4 cm (without mounting brackets)
- Weight: approx 2.7 kg
- Operating temperature: 0-50 °C
- Storage temperature: -20 – 70 °C
- Relative humidity: 0 – 95 % (non condensing)
Electrical Connections
- 1 power supply IEC C20 (max. 16 A, 230 V)
- 4 power ports IEC C13 (max. 10 A)
- 1 Ethernet connector RJ45 (10/100 Mbit/s)
- 1 serial interface RS232 (Sub-D, 9-pin)
- 2 sensor connectors (RJ45) for plug-&-play sensors
