- Specifications
- Input Channel
- MIC
AUX
CHAT (*1)
GAME (*1)
MUSIC (*1)
SYSTEM (*1)
USB (*2)
(*1) When the USB port connection setting is "PC"
(*2) When the USB port connection setting is "CONSOLE/MOBILE" - Output Channel
- LINE OUT
PHONES
MIC (*3)
STREAM (*3)
PERSONAL (*3)
USB(*4)
(*3) When the USB port connection setting is "PC"
(*4) When the USB port connection setting is "CONSOLE/MOBILE" - Connectors
- MIC jack: XLR type (Phantom power DC 48 V, 6 mA Max)
PHONES/HEADSET jack: Stereo miniature phone type (CTIA, PLUG-IN power)
AUX jack: Stereo miniature phone type (TRRS)
LINE OUT jack: Stereo miniature phone type (TRS)
USB port: USB Type-C (R)
USB DC 5V port: USB Type-C - Audio Mixing Bus
- 2 (STREAM MIX, PERSONAL MIX)
- Sampling Frequency
- 44.1 kHz, 48 kHz, 96 kHz
- Signal Processing
- AD/DA: 24 bits
Internal Processing: 32-bit Floating point - Effects
- MIC: Voice Changer, Noise Suppressor, Compressor, Equalizer, De-esser, Reverb, Low Cut
CHAT: De-esser, Compressor
GAME: Equalizer
STREAM: Delay - Audio File Player
- Number of tracks: 2
Data Formats: WAV (Linear PCM, 48 kHz, 16 bits, stereo/mono)
Maximum Time: 5 seconds/track - Input Level
- MIC: -85.5--10.5 dBu (Maximum: +1.5 dBu)
HEADSET MIC: -58.5--20.5 dBu (Maximum: -8.5 dBu)
AUX: -10 dBu (Maximum: +2 dBu) - Input Impedance
- MIC: 3.4 k ohms
HEADSET MIC: 1.3 k ohms
AUX: 10 k ohms - Output Level
- LINE OUT: -4 dBu (Maximum: +8 dBu)
PHONES/HEADSET: -1 dBu (Maximum: +11 dBu)
PHONES/HEADSET: 78 mW + 78 mW (32 ohms)
PHONES/HEADSET: 35 mW + 35 mW (250 ohms) - Output Impedance
- LINE OUT: 1 k ohm
PHONES/HEADSET: 10 ohms - Power
- USB bus power
USB AC adaptor (commercially available)
* Use an USB AC adaptor that can supply 5 V, 1.0 A or more. - Current Draw
- 5 V DC, 900 mA
- Operating System
- Microsoft Windows 10, Windows 11
Apple macOS 11 or later
Apple iOS 15 or later
* Although Roland has tested numerous configurations, and has determined that on average, a computer system similar to that described above will permit normal operation of the BRIDGE CAST, Roland cannot guarantee that a given computer can be used satisfactorily with the BRIDGE CAST based solely on the fact that it meets the above requirements. This is because there are too many other variables that may influence the processing environment, including differences in motherboard design and the particular combination of other devices involved. - Accessories
- Leaflet "Read Me First"
USB 2.0 Type-C to Type-C Cable (2 m, 6.5 feet)
USB 2.0 Type-C to Type-A Cable (2 m, 6.5 feet) - Size and Weight
- Width
- 222 mm
8.7 inches - Depth
- 110 mm
4.3 inches - Height
- 70 mm
2.8 inches - Weight
- 450 g
1 lb
