5.25" 2way IP Dante/AES67 POE Kabinett Værsikre - Sort
| Generelle spesifikasjoner | |
|---|---|
| Bruttovekt | N/A kg |
| Farge | Sort |
| Dante | Ja |
| Produsentens varenummer | IPD-SM52-EZ-WX-BK |
SoundTube IPD-SM52-EZ-WX IP-Addressable Speaker in Black
The IPD-SM52-EZ-WX is a Dante-enabled, weather resistant, digital end-point solution in a surface-mount loud speaker. This speaker includes a 40 W PoE amplifier for simplified installation and set up. Driver components consists of one 5.25 inch polypropylene woofer and one 1.0 inch soft dome tweeter in a ported enclosure. The included pre-mountable surface-mount bracket allows for quick and easy installation and the powder-coated aluminum grille keep the speaker looking good in most environments. The system is UL 60065 approved. IP-Rating: IP65. Included accessories: Safety cable, wall mount bracket, conduit connector and port plug. If used outdoors, port plugs must be installed to ensure protection from moisture.
*Note: If used indoors, remove the grille and take the plug out of the port for greater bass output. Port must remain plugged to maintain IP65 rating in outdoor use.
ColorBlack
UPC752830447585
ManufacturerSoundTube
Manufacturer's CategorySTNet IP-Addressable and Dante Series
Depth6.63 in / 168.4 mm
Height11.88 in / 301.75 mm
Width/Diameter7.5 in / 190.5 mm
Shipping Weight7.8 lbs / 3.54 kg
Carton Height12 in / 304.8 mm
Carton Length15 in / 381 mm
Carton Width10.5 in / 266.7 mm
CertificationsCE, IP65, RoHS, UL60065
Included AccessoriesMounting Hardware, Port Plug, Safety Cable
Source InputsRJ45 Ethernet Port
IP RatingIP65
TAA Compliant (Trade America)No
BAA Compliant (Made in USA)No
Coverage Angle (±6dB @ 2kHz)91° Horizontal / 120° Vertical
Crossover Frequency3.5 kHz
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz)6.9 and 5.9
Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz)5.2 and 7.7
Frequency Response (± 10 dB)55 Hz - 20 kHz | Sealed: 62 Hz - 20 kHz
Frequency Response (± 3 dB)65 Hz - 20 kHz | Sealed: 80 Hz - 20 kHz
Grille PropertiesAluminum, Black, Powder-Coated
Low Frequency Voice Coil25.4 mm (1") high temperature Kapton
Max SPL @ 1M97 dB
Tweeter Driver1" Soft Dome
Woofer Driver5.25" Polypropylene Cone w/ Butyl Rubber Surround
